Description
CFB-Plus Series Cartridges are an enhanced version of Pentair CFB Cartridges. They offer the same benefits with even greater chlorine taste & odor reduction and the highest sediment reduction found in a carbon cartridge
They utilize Fibredyne’s proprietary molded carbon block technology for high dirt-loading capacity and up to twice the chlorine, taste and odor reduction of traditional carbon blocks, while maintaining low pressure drops.
- Better chlorine reduction and 5 micron sediment filtration for residential chlorinated water supplies
- Standard 2.5″ diameter by 10″ length
- Best dirt holding capacity, significantly minimizing pressure drop through life of cartridge
The latest in carbon technology, Pentair Fibredyne stands for best of both worlds: a range of cartridges that combine activated carbon technology with depth filtration. This allows all the benefits of activated carbon with minimum pressure drop, thanks to using powdered activated carbon embedded in a polyethylene matrix. With premium chlorine, taste and odour reduction, the CFB-Plus is a versatile cartridge, with the highest sediment reduction promoting a long life and the ideal, trusted choice for residential, commercial or industrial applications.
Pentair 2025CFB-PLUS – Key Features
- Useful for domestic and general water supply
- Fibredyne technology enables one- stage chlorine and sediment removal, promoting ease of use
- Unique post-filtration layer eliminates fine release downstream
- Perfect for cleaning up incoming water for breweries
- Over 75% reduction in pressure drop compared to carbon block filters
Pentair 2025CFB-PLUS Specifications
- Micron rating: 5 Micron (µm)
- Length: 20 inches (510mm)
- Diameter: 2.5 inches (65mm
- Compliance: NSF/ANSI 42 Certified
- Max operating temperature: 82 degrees C
- Max. Operating Pressure Diferential: 1.5 bar
- Carbon Type: Bonded Powder Activated Coconut Carbon
- End-cap: Polypropylene
- Netting: Polyethylene
- Gasket: Santoprene
CFB-Plus Chlorine Reduction Properties
| Length (“) | Chlorine Reduction (L) @ 2mg/l * |
Chlorine Reduction (L) @ 0.2mg/l ** |
Pressure drop (Bar) @ | Flow Rate (LPM) |
| 10 | 37,800 | 330,750 | 0.11 | 3.8 |
| 20 | 75,700 | 662,375 | 0.11 | 7.6 |
| 30 | 113,500 | 993,125 | 0.11 | 11.4 |
| 10BB | 94,600 | 827,750 | 0.17 | 7.6 |
| 20BB | 189,000 | 1,653,750 | 0.17 | 15.1 |
*Chlorine capacity using 2mg/l free available chlorine at 0.5mg/l breakthrough
**Calculated chlorine capacity using 0.2mg/l free available chlorine at 0.05mg/l breakthrough
